Key Cutting Machines

Mul-T-Lock Machinery's compact manual key-cutting machine is a modern, high-precision, CE-certified machine that cuts Mul-T-Lock cut-to-code keys for the Classic and Interactive^®+ series.

Set to the correct combination via the key registration card − included in the original package sold to the customer − the machine cuts keys according to the manufacturer's initial specifications. Cutting is performed one side at a time, allowing for a different combination on either side of a single key blank.

Features

• Capable of cutting side and back pins.
• Lightweight: weighing only 20.6 kg (45 lbs)
• Equipped with a handle for portability.
• The machine can be used in vehicles with a suitable power supply (not included).
• Available in 110 and 220 volt versions.



Specifications

• Width: 245 mm (9 ⅝")
• Height: 327 mm (12 ⅞")
• Depth: 355 mm (14")
• Motor: Single phase 245W
• Voltage: 110v 60Hz; 100v 60Hz/50Hz (Japan); 220v 50Hz
• Weight: 20.6kg (45 lbs)
• Approval: CE Machinery Directive (89/392/EEC)

Description
KC5^™ is Mul-T-Lock Machinery's perfect answer for the modern-day locksmith in search of new professional horizons.
Computerized, intelligent and automatic, this elegant key-cutting platform responds to the needs of all customers − large and small, and from single key orders to extensive projects requiring complex security solutions.

Compatible with all Mul-T-Lock cylinder platforms including the ground-breaking MTL^™800, KC5^™ offers cut-to-code capabilities based on magnetic card readings, as well as key marking features together with user-friendly software.

A web-based Machine Management System specially developed by Mul-T-Lock provides this smart machine with advanced configuration, authorization and service management capabilities.

Specifications
Width: 500 mm (19.7")
Height: 360 mm (14.2")
Depth: 340 mm (13.4")
Motor: Single phase 300W
Voltage: 110v 60 Hz; 220v 50 Hz
Weight: 32kg (71.5 lb.)
Approval: CE Machinery Directive (89/392/EEC)
