Function

The electromechanical CLIQ^® cylinder is used in combination with the CLIQ^® key enabling the collection and storage of information about when the cylinder has been accessed and with which key.
In addition, the cylinder stores a list of authorized and unauthorized CLIQ^® keys to ensure only enabled keys have access.

Applications
The CLIQ^® cylinder is based on Mul-T-Lock's High Security mechanical platforms Interactive^®+ and MT5^®.
It is available in a wide range of cylinder applications including Euro (double or single), rim, mortise, kik, padlocks, switch cylinder and more.

Features
Audit trail standard memory: 100 events
Audit trail extended memory: 1000 events

Specifications
IP54 (IPx8 with anti-water coating protection)
Temperature range: -20°C - +60°C
Encrypted (3DES) communication between cylinder and key/c-key
Available in a variety of finishes
Minimum length: 33 mm (Euro model)
Power supplied via the CLIQ^® key's embedded battery

Application

Compatible with locks and lock cases using Euro profile cylinder.

Operation
360˚ rotation with operating key or thumbturn.
Standard double cylinder, full key insertion disengages opposite side.

Materials
Body and plug: high-quality brass
Cam and cogwheel: steel
Pins: nickel silver and stainless steel

Standard Finishes
Nickel satin; Brass; Shiny brass

Special Finishes
Nickel chrome; Antique brass

Cylinder Mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder Platforms
Classic, MTL^™400, MTL^™600, MTL^™800

Cylinder options
'3 IN 1' (changeable combination)
Keyed different
Keyed alike
Master keyed
Variety of thumbturns, cams and cogwheels
Emergency cylinder with both sides permanently operational

Standards
ISI950; EN1303

Application

Compatible with "ASSA" lock cases.

Operation
360˚ rotation with operating key.

Options
Pair of internal and external cylinders
External cylinder only

Materials
Body and plug: high-quality brass
Cam: steel
Pins: nickel silver and stainless steel

Standard finishes
Nickel satin; Brass

Cylinder Mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.
Internal cylinder with 4 chambers.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder Platforms
Classic; MTL^™600, MTL^™800

Cylinder options
'3 IN 1' (changeable combination)
Keyed different
Keyed alike
Master keyed

Application

These cylinders are used in cylindrical locksets, deadbolts and padlocks. Mul-T-Lock^® provides an extensive range to fit a wide variety of popular brands.

Operation

Rotation by operating key.

Materials

Body and plug: high quality brass Tail pieces: steel

Pins: nickel silver and stainless steel

Standard finish

Satin Chrome, Shiny brass

Special finishes

Oil Rubbed Bronze

Cylinder Mechanism

Mul-T-Lock’s unique, high precision pin tumbler system.

Keys

Reversible nickel silver key with plastic key head and colored insert. Also available in all nickel silver.

Cylinder options

• Classic, MTL^™400, MTL^™600 & MTL^™800 platforms

• ‘3 IN 1’ (changeable combination)

• Keyed different, keyed alike

• Master keyed

Application
Compatible with residential and commercial surface mounted door locksets, interfaces with locksets of major brands.
Suitable for a wide range of lock mechanisms.

Operation
360˚ rotation with operating key.

Materials
Body and plug: high-quality brass
Tail: steel
Pins: nickel silver and stainless steel

Standard finishes
Nickel chrome matte; Nickel chrome; Shiny brass

Special finishes
Antique bronze; Black; Antique brass; PVD

Cylinder Mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder platforms
Classic; MTL^™600, MTL^™800

Cylinder options
'3 IN 1' (changeable combination)
Keyed different
Keyed alike
Master keyed
Variety of tails

Standards
ISI950

Application

Dual purpose cylinder, combining rim and mortise cylinders in one. Compatible with residential and commercial door locksets.

Operation
360˚ rotation with operating key.

Materials
Body and plug: high-quality brass
Cam: steel
Pins: nickel silver and stainless steel

Standard finishes
Shiny brass, satin chrome, oil rubbed bronze

Special finishes
Black; Antique brass;

Cylinder mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder platforms
Classic; MTL^™400, MTL^™600, MTL^™800,
Cylinder options
'3 IN 1' (changeable combination)
Keyed different
Keyed alike
Master keyed

Standards
ISI950

Application

Compatible with residential and commercial door locksets.
Interfaces with locksets of major brands (see available cams).
Can retrofit a 'Jumbo' cylinder with an adaptor ring.

Operation
360˚ rotation with operating key or thumbturn.

Materials
Body and plug: high-quality brass
Cam: steel
Pins: nickel silver and stainless steel

Standard finishes
Nickel chrome matte; Nickel chrome; Shiny brass

Special finishes
Antique bronze; Black; Antique brass; PVD

Cylinder mechanism
Mul-T-Lock's unique, high-precision pin tumbler system.

Keys
Reversible nickel silver key with plastic key head and colored insert.
Also available in all nickel silver.

Cylinder platforms


Cylinder options

• Classic; Interactive^®+; MT5^®

Platforms

• '3 IN 1' (changeable combination)
• Keyed different, Keyed alike
• Master keyed
• Variety of cams

Standards
ISI950
