A robust wireless device to bring secure RFID and BLE unlocking to every high-traffic door. i-max, an electronic escutcheon is easy to retrofit and compatible with Standalone, UOC, online or offline system management.

Application

SMARTair i-max comes in a variety of finishes and with a slimline design to fit every building style and scheme. Different models of handles and antibacterial surface for healthcare applications are available.

Technical Data
Door profiles - Suitable for wooden, narrow or glass doors
Traffic volume - meduim to high
Exterior usage - IP54 (Xetreme version) Up to 85% humidity -20 °C to +70 °C
Hardware compatibility and installation - High retrofit (compatible with most common mortise locks). Drilling, no cabling. Doors from 30mm up to 110mm (thicker doors may be possible on demand)
Power supply - Battery (from 60.000 to 80.000 cycles)* max. 2 years standby**
Types of batteries:: 3 LR03 AAA 1.5V alkaline batteries
Multi-authentication - RFID and PIN
Status informatin - Handle usage. Thumb turn usage: only in privacy model/ door position: door sensor ot included. No (normally open) connection. Override cylinder (in combination with special mortise lock)
Certification - CE (EMC, R&TTE). ROHS, REACH, WEE. EN1634 (Fire)
RFID tegnologies - HID iClass(R). MIFARE Classic and Ultralight SKIDATA. DESFire.
System management upgradability - Escutcheons can be upgraded from standalone > Offline. Update on Card > Wireless online by:
- Adding RF Module
- Fireware upgrade
- Change of internal cover (plastic top)

* Depending on reading technology (MIFARE), iClass etc.)
** Depending on cycles per day.

Function

For the ultimate in access flexibility, SMARTair TS1000 software enables system admin from any device. Manage offline, Update on Card and online devices within the same installation and one interface.

The SMARTair TS1000 software is the most intuitive management software on the market. It brings flexibility and — if required — real-time control to any installation. Easy upgradability, a core SMARTair philosophy, is right at the heart of your TS1000 software user experience.

SMARTair TS1000 puts managers in complete control of all access from a single point. Its secure client–server architecture with web services allows system management from virtually any device — PC, tablet or smartphone — and from multiple points. There is no need for managers to stay physically at their site, and no software for clients to install.

With the SMARTair TS1000 software, facilities and security managers can opt to manage access rights with calendar schedules for different user groups. The system offers ongoing flexibility, easily incorporating new doors, new users and permissions, calendars and time zones. Up to 30 separate schedules can be incorporated.

With SMARTair TS1000 software, you can easily combine different management systems within one installation. For example, perimeter doors are equipped with Wireless Online functionality, while many interior doors are managed by Update on Card. A single software interface controls it all.

The TS1000 also offers the capability to upgrade quickly from Offline to Update on Card or Wireless Online management. Your investment is future-proofed, because SMARTair’s software does the upgrading for you.

The SMARTair Management Software includes:

A USB memory device that contains: SMARTair Software installation file; Site data (the license); Technical manuals
Authorization key programmed with the system's code
The easy-to-use SMARTair Software manages all types of SMARTair products − escutcheons, wall readers, cabinet lock, knob cylinders and others − simultaneously.


Software requirements

PC with Pentium 4 processor or higher
1 GB of free RAM
1 GB or free disk space
32-bit or 64-bit Microsoft Windows Operating System supporting services (Windows 95, Windows 98 and Windows ME are not supported)

Site data

The 'site data' is supplied with the software and includes the license for the system and a unique 8-figure alphanumeric system code
All information regarding the system (user list, door list, authorization matrix, time profiles, etc.) is kept in the site data file

Authorization Key

The Authorization Key enhances security for the SMARTair system
Each Authorization Key contains the system's unique corresponding
system code
In order for the Portable Programmer to function, the Authorization Key must be inserted. Without it, the Portable Programmer will not update the door or retrieve audit trails. It is possible to override the Portable Programmer by logging into the system's software

Types of licenses

For the different products (upgrades available): Offline; Update-On-Card (UOC); Wireless
According to the number of doors in the system (upgrade available): Up to 10 doors; Up to 30 doors; Up to 75 doors; More then 75 doors
With Anti-Pass Back functionality (this feature is available with any license)

Function

The SMARTair Knob Cylinder is an easy-to-use, simple-to-install, and highly effective electronic cylinder that can be integrated with other SMARTair locking elements − escutcheons, wall readers, e-motion − in one Access Control system managed by SMARTair Software.

The Knob Cylinder is upgradable from Standalone to Offline/Update-On-Card and/or Wireless, making it the perfect solution for both new and retrofit installations.

The SMARTair knob cylinder world-class design is robust and resistant. The knob cylinder comes in more finishes and colors, upgrading aesthetics and functionality in equal measure. Suitable for any door, it quickly upgrades your existing mechanical cylinder to a real-time access-controlled cylinder – without any drilling or wiring at the door.

Mechanical features

Freewheeling knob until an authorized credential is presented
Motorized clutch activates cylinder cam
Compatible with a mass variety of standard mortise locks (Euro, Scandinavian, Finnish and ANSI models are available)
Panic function: Internal knob turning always opens door (only Euro model)
Available Knob Cylinder models:
Euro - Double cylinder (one or two electronic sides), half cylinder,

Mortise cylinder

Scandinavian - Double cylinder (one or two electronic sides), half cylinder

Application

The new SMARTair knob cylinder is a wireless locking device designed for office and meeting room doors, as well as existing glass, aluminum or wooden doors where installing an escutcheon proves difficult.
